Click on Edit (from the menu bar), then Copy OPC/DDE topic.įinally, browse for the tag “MyTimer.ACC” as shown, then press OK.Īt last, I will open the spreadsheet program. Thirdly, we need to copy the link from RSLinx, so we can paste the topic into our spreadsheet.
RSLINX CLASSIC LITE 3.60.00 UPDATE
If you need this to update faster, go to the “Data Collection” tab, to change the update time. Be sure the name of the topic, and the processor are both highlighted at the same time. Then I created a topic named “MyTopic”, and pointed this shortcut to the processor. In order to access the topics, we will open RSLinx. The topic will act as a “shortcut” to our processor.
RSLINX CLASSIC LITE 3.60.00 HOW TO
I’ve set up this timer simply to demonstrate how to display the data in a spreadsheet. When the accumulated value of the timer reaches, the preset, this timer will start all over. Our goal in this example is to display the accumulated value in an OpenOffice (Or LibreOffice) spreadsheet.
Exampleįirst of all, let’s take a look at some code in the processor. You can also use this feature for reporting, trending, etc. The next time the equipment fails, you can simply open the spreadsheet to see what condition is not met. If your equipment fails to start, you can open a spreadsheet that has all of the conditions listed that must be met before the equipment will run. One reason is to create a troubleshooting tool. There are many reasons you would want to do this.
